SOLAX POWER T-BAT SYS-HV-S3.6 lagernd

📦 Note: This product has a delivery time of 6-8 weeks.

The SOLAX POWER T-BAT SYS-HV-S2.5 is a single battery module of the modular T-BAT high-voltage storage system with 2.56 kWh capacity – without integrated BMS. The compact basic unit for building your individual energy storage system.

Product features:

Flexible scalability

• Stackable module design: Expandable from 5.12 kWh to 33.28 kWh total capacity
• Plug-and-play installation for quick commissioning
• Only combinable with other HV-S2.5 modules

High-performance technology

• LiFePO4 (LFP) battery cells for maximum safety and longevity
• Over 6,000 charge cycles lifespan
• Max. 50A charge/discharge current
• No integrated BMS – external BMS (TP-HV25 Tower Box) required

Robust construction

• IP55 protection class for safe operation
• Integrated battery heating for operation at low temperatures
• Soft-start function to protect against sudden power surges
• Automatic fire suppression (ammonia suppression)

Technical data:

• Capacity: 2.56 kWh
• Nominal voltage: 102.4 V | Operating range: 90–118.4 V
• Dimensions (W×D×H): 510 × 322 × 545 mm | Weight: approx. 80 kg
• Communication: CAN, RS485

The HV-S2.5 module is the ideal basis for your individual energy storage system – without BMS, maximum flexibility.
